ETU – Introduction
Why a complex instrument should use a complex interface ? Trying to address this question leads us to rethink all of our softwares to turn them really easy to use. We had to forget all the way we develop softwares since decades and from a white paper, we imagined a new design that can hold advanced functionality together with intuitive touch-screen control in a unique window.
After years of works and reflexion we are proud to introduce you Cameca Tactis ETU software ! Tactis ETU is part of PeakSight 6.3 and later versions and offers new users experiences to the SX- FIVE Tactis community.
Tactis allows to have a one-screen access to the main PeakSight functionalities. Controls surround the real time imaging screen (RTI) that displays optical and electronic images but also X-rays maps. Settings for experiment are available through the five tabs ‘Setup/Stage’, ‘µscope’, ‘SEM’, ‘X-Live’, ‘X-Map’ and ‘Quanti’.
As we created a new efficient tool dedicated for microanalysis we wanted also to offer you a new experience for support and assistance. That’s why we developed a new generation of helpdesk, focused on step-by-step action description. This helpdesk is a giant tutorial that will guide you all along your analysis from the optical observation to the chemical quantification.
Related Article
Start With Tactis ETU Software
Reading Duration 6min
Tactis ETU Software is a part of PeakSight 6.3 and late.
ETU – Setup/Stage
Reading Duration 4min
This part describes the SETUP/STAGE tab
Optical Microscopy
Reading Duration 4min
This article presents, in a tutorial mode, how to display and acquire high-quality images from optical microscopy system of the SX-FIVE. Functions are spread into ’Optical microscopy’ (all the hardware controls), ‘Save’ and ‘Mosaic’ subsections.
Scanning Electron Microscopy
Reading Duration 11min
Electronic images are provide though the Scanning Electron Microscopy functionalities of the SX-FIVE. Three detectors are available.
ETU – XLive
Reading Duration 10min
X Live is a powerful tool designed to draw real time X images using WDS or EDS detection. Images can be acquired separately or as a composite including SEM image as background.
ETU – XImages
Reading Duration 5min
This tab is dedicated to the acquisition of high resolution / high count rate chemical maps.
ETU – Quanti/Check
Reading Duration 18min
The ‘Quanti’ tab provides all the tools necessary to get quantified chemical analysis of any solid sample, but also a range of check procedures to ensure the instrument hardware is well set. Both of them can be reach though the sub-tabs ‘Quanti’ and ‘Check’.
ETU – Configuration – Menu
Reading Duration 10min
Configuration window allows to set ‘Focus Auto Config’, ‘Astigmatism Auto Config’, ‘Expert System Config’, ‘Check standard Config’ and ‘Check Machine Config’.
